DESIGNED FOR SPEED – 20 M/S² ACCELERATION – COREXY 20M

How is this speed achieved?
Ultra lightweight carbon rail

40 w ceramic heater

Powerful 12 w cooling fan

Welded steel xy chassis
SPAGHETTI FAILURE DETECTION

X1-Carbon integrated AI keeps an eye out for Spaghetti monsters, so you can sleep easy in the knowledge that your printer is safe from this scourge. A spaghetti failure is detected with confidence of 86%.
ADVANCE MATERIAL EMPOWER ADVANCED PROJECTS

Bambu Lab X1 Carbon, equipped with extra cooling and a hardened nozzle and carburized drive gear, unlocks a wider selection of materials, including PA, PC, PET, and TPU, and specializes in carbon fiber and glass fiber reinforced polymers.
MICRO LIDAR ASSISTED BED LEVELING

Bambu Micro Lidar brings micrometer level precision into 3D printing. The system probes the nozzle height, calibrates the flow, and scans the first layer, so the possibilities are endless.
Specifications
Build Volume (W×D×H)

256 × 256 × 256 mm³
Nozzle

0.4 mm Hardened Steel Included (Plus 1x 0.6 mm with Carbon Fiber Bundle)
Hotend

All-Metal
Max Hot End Temperature

300 ℃
Filament Diameter

1.75 mm
Supported Filament

PLA, PETG, TPU, ABS, ASA, PVA, PET Ideal for PA, PC, Carbon/ Glass Fiber Reinforced Polymer
Build Plate Surface

Bambu Cool Plate, Bambu Engineering Plate Included
Max Build Plate Temperature

110℃@220V, 120℃@110V
Max Speed of Tool Head

500 mm/s
Max Acceleration of Tool Head

20 m/s²
Physical Dimensions

389 × 389 × 457 mm³, Package size 480 × 480 × 590 mm³, Net weight 14.13 kg, Gross weight(AMS included) 22.3 kg
Electrical Requirements

100-240 VAC, 50/60 H, 1000W@220V, 350W@110V
